Welcome to Ormond Energy Innovations Inc.

What is FiberSafe™ ?

FiberSafe™ is a patented technology platform that holistically addresses the inherent drawbacks of existing subsea fiber optic systems. The technology platform provides robust and inherently reliable end-to-end harsh environment fiber optic communication network architecture that is CAPEX friendly with affordable subsea fiber optic hardware.


What are the inherent drawbacks of existing systems?

Harsh  environment cables such as submarine/ telecom cables have demonstrated  exceptional reliability, primarily due to its  construction involving  protective layers housing the optical fibers.  But, existing subsea fiber optic systems involve  elimination  of those protective layers with, optical fiber break-out,  complicated  feed-through, and harsh environment loading (including  differential  pressure loading) of the fragile optical fibers. Additionally, the cable  sealing equipment is non-pressure balanced with blind seals  that cannot be tested prior to deployment. From a commercial standpoint,  existing industry solutions are a) bulky with larger footprint b)  non-value adding supply chain and associated risks c) expensive overall  system cost.

FiberSafe™ - Core Technology

FiberSafe™ technology is based on a simple premise that optical fibers shall be protectively maintained without being exposed to harsh environment. As a result, optical fibers integrity is preserved from source (such as topsides) to end-instrument (such as subsea equipment).


Optical fibers in the entire network are protected from the effects of harsh environment, by hermetic tubes, protective storage, hermetic manifold, and hermetic fiber connector contact tube string in a gel filled non-pressurized environment. Furthermore, the above stated optical fiber protecting boundaries are isolated from seawater by sealed housings containing pressure balancing benign fluid.


This technology is applicable to any harsh environment i.e., subsea application, land based oil and gas application (shale), harsh terrestrial, space and aerospace.


This novel approach and technology building blocks enables configurable, application suited affordable solutions in comparison to cost-prohibitive status-quo exposed fiber systems.

FiberSafe™ Fiber Optic Equipment and Services

Please follow the link below to get to "Order Page" for enquiries, RFQ, and how to place an order for  FiberSafe™ technology fiber optic equipment and services.

FiberSafe™ Features

Protected Optical Fibers

On-site seal test pre-deployment

Truly pressure balanced system


Optical fibers are maintained in a multi-layer gel filled protective environment in a stress-free state isolated from seawater, chemicals, hydrogen and other gases under all circumstances.

Truly pressure balanced system

On-site seal test pre-deployment

Truly pressure balanced system


All FiberSafe™ hardware are truly pressure balanced equipment, thereby eliminating the detrimental effects of differential pressure applied over the fiber optic system.

On-site seal test pre-deployment

On-site seal test pre-deployment

On-site seal test pre-deployment


All seals in the FiberSafe™ system hardware, including field assembled termination seals interfacing submarine cable, are fully testable to verify integrity of the assembly prior to subsea deployment. On-site seal test options include gas testing, hydraulic testing.

Protected Electro-Optic variant

Protected Electro-Optic variant

On-site seal test pre-deployment


FiberSafe™ technology principles are applicable to submarine cables with electrical conductor and optical fibers. Electrical conductor, electronics/opto-electronics and optical fibers are protectively maintained stress-free in a multi-layer gel filled environment.

Smaller Footprint

Protected Electro-Optic variant

Smaller Footprint


FiberSafe™ configurable building blocks and the core technology enables smaller footprint hardware design and installation friendly overall system architecture.

Configurable

Protected Electro-Optic variant

Smaller Footprint


FiberSafe™ system configurable for

  • primary coordinate space parameters involving a)subsea conditions b) seals & materials c) joining methods
  • secondary coordinate space parameters involving circuit density and hardware specific packaging integration

Configuration flexibility enables packaging possibilities and cost-efficiency with rightly-engineered system that are affordable and CAPEX friendly.

FiberSafe™ in the news


Ocean News & Technology Magazine - March 2018 - Product Spotlight

FiberSafe™ was featured as product spotlight in March 2018 editorial of industry rewnowned Ocean News & Technology Magazine ON&T.


http://digital.oceannews.com/publication/?i=479255&ver=html5&p=31
